Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Expansion Module | |
| Quantity of Slots | 8 |
| Supported Module | I-8K series, I-87K series |
Industrial Interfaces | |
| Profibus DP Version | 1 |
Supported Protocols | |
| Industrial Protocols | Profibus slave |
Connectors | |
| Connectors | Screw Terminal |
Dimensions and weight | |
| Width | 312 mm |
| Depth | 91 mm |
| Height | 132 mm |
System Power Input | |
| Input Voltage DC | 10...30 V |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
