Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 1 U |
| Type | Fans |
CPU | |
| Processor Installed | Intel Xeon E-2136 |
| Max CPU frequency | 4.5 GHz |
Chipset | |
| Chipset | Intel C246 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| ECC | Yes |
| Maximum Memory | 32 GB |
Ethernet | |
| Controller Type | Intel i211 |
| Total Ethernet | 8 |
| 10/100/1000 Mbit/s | 8 |
Interfaces | |
| USB Total | 6 |
| USB 2.0 | 4 |
| USB v3.x | 2 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Extension Slots | |
| Total | 4 |
| PCI Express x8 | 1 |
| PCI Express x4 | 1 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | 1xHDD LED, 1xOn/Off LED, Power LED, FAULT LED |
| Controls | On/Off |
Connectors | |
| Internal Ports | 4xUSB 2.0 |
| Connectors | 2xUSB, AC Input, Console Port RS-232 (RJ-45), 1xSMA, 8xRJ45 Ethernet |
System Power Input | |
| Input Voltage AC | 90...264 V |
Power Supply | |
| Type of Power Supply | Redundant |
| Output Power | 300 W |
Software | |
| Operating System Compatibility | Ubuntu |
Dimensions and weight | |
| Width | 430 mm |
| Height | 44.2 mm |
| Depth | 426 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE |
