Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 1 U |
| Type | Fans |
CPU | |
| Processor Installed | Intel Pentium Gold G5400T |
| Max CPU frequency | 3.1 GHz |
Chipset | |
| Chipset | Intel H310 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| ECC | No |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | HDMI |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 6 |
| 10/100/1000 Mbit/s | 6 |
Interfaces | |
| USB Total | 4 |
| USB 2.0 | 2 |
| USB v3.x | 2 |
Extension Slots | |
| Total | 3 |
| PCI Express x16 | 1 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | LED Bar, 1xHDD LED, Module Fail, 1xOn/Off LED, Power LED |
| Controls | On/Off, 1xReset, AT/ATX Switch |
Connectors | |
| Internal Ports | 2xUSB 2.0, HDMI |
| Connectors | 6xRJ45 Ethernet, 2xUSB, AC Input, RJ45 (Console) |
System Power Input | |
| Input Voltage AC | 90...264 V |
Power Supply | |
| Output Power | 250 W |
Software | |
| Operating System Compatibility | Ubuntu |
Dimensions and weight | |
| Width | 430 mm |
| Height | 44.2 mm |
| Depth | 320 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
