Construction | |
| Mounting Configuration | 19" Rackmount |
| Height | 2 U |
| Type | Fans |
CPU | |
| СPU Generation/Family | Ice Lake |
| Socket | LGA4189 |
| CPU Support Type | Xeon |
| Number of CPU | 2 |
Chipset | |
| Chipset | Intel C627A |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 20xDIMM |
| ECC | Yes |
| Maximum Memory | 1280 GB |
| Assembly | Removable |
Graphic | |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219 |
| Total Ethernet | 2 |
Interfaces | |
| USB Total | 3 |
| USB 2.0 | 1 |
| USB v3.x | 2 |
Extension Slots | |
| Total | 4 |
| PCI Express x8 | 1 |
| M.2 | 2 |
LED / Controls | |
| LED | 1xHDD LED, Power LED, FAULT LED |
| Controls | On/Off, 1xReset |
| Setup of Operation Mode | Console Port |
Connectors | |
| Internal Ports | USB 2.0 |
| Connectors | DB15 VGA, RJ45 Ethernet, 2xUSB, RJ45 (Console) |
System Power Input | |
| Input Voltage AC | 100...240 V |
Power Supply | |
| Type of Power Supply | Redundant |
| Output Power | 1200 W |
| Quantity of Power Modules | 2 |
Software | |
| Operating System Compatibility | Ubuntu, Red Hat Linux, CentOS Linux, Windows Server 2019 |
Dimensions and weight | |
| Width | 438 mm |
| Height | 88 mm |
| Depth | 650 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
