Construction | |
| Construction Chassis | Rubber |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fan |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.1 " |
| Brightness | 1000 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Kaby Lake |
| Processor Installed | Intel Core i5-8250U |
| Max CPU frequency | 3.4 GHz |
Memory | |
| Form-factor | DDR4 |
| Default on Board Memory | 8 GB |
| Maximum Memory | 16 GB |
Graphic | |
| Graphic Controller | Intel UHD Graphics 620 |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n/ac |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Installed drive | |
| Drive Interface | SATA |
| 1st Storage Capacity | 128 GB |
Additional Functions | |
| Camera Frontside | 2 MP |
| Rear Camera | 8 MP |
| GPS | GPS |
Antenna characteristics | |
| Cellular interfaces | 4G (Optional) |
| Bluetooth | v4.2 |
Connectors | |
| Connectors | USB type A, USB type C, RJ45 Ethernet, DB9, Audio, Micro HDMI, Micro-SIM card slot |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 65 W |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 4500 mA*h |
| RunTime Battery 1 | 12 h |
| Battery 1 Hotswap | Yes |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10 |
| Operating System Installed | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 280 mm |
| Height | 195 mm |
| Depth | 23 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
