Construction |
| Construction Chassis | Rubber |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
Display |
| Display Type | LCD |
| Diagonal | 10.1 " |
| Maximum resolution | 1920x1200 Dots |
| Brightness | 1000 Cd/m2 |
Touch Screen |
| Touch Screen Type | Capacitive |
CPU |
| Processor Installed | Intel Core i5-7300U |
| Max CPU frequency | 3.5 GHz |
Memory |
| Form-factor | DDR4 |
| Default on Board Memory | 8 GB |
Ethernet |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi |
| Wi-Fi Standard | 802.11a/b/g/n/ac |
Interfaces |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 3 |
| USB v3.x | 2 |
Drive interfaces |
| mSATA | 1 |
| MicroSD | 1 |
Installed drive |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 128 GB |
Extension Slots |
| SIM Card slots | Micro-SIM, Yes |
Additional Functions |
| Camera Frontside | 2 MP |
| Rear Camera | 8 MP |
| GPS | GPS |
| MSR Reader | Optional |
| Smart Card Reader | Optional |
| NFC | Yes |
| Sensors | Light Sensor, G-sensor, Gyroscope, Accelerometer |
Antenna characteristics |
| Cellular interfaces | 3G, 4G |
| Bluetooth | v4.0 |
LED / Controls |
| LED | Battеry Status, 1xOn/Off LED, WLAN LED |
| Controls | On/Off, Control Buttons, Function Keys, Volume Keys |
Connectors |
| Connectors | DB9, RJ45 Ethernet, 2xUSB, Audio (in/out/Mic), MicroSD card slot, Micro HDMI, Micro-SIM card slot |
| Docking Station | Yes |
Power Supply |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 65 W |
| Supported Types of Power Supply | External power adapter AC/DC |
| Input Voltage AC | 100...240 V |
Battery |
| Battery Capacity | 4500 mA*h |
| RunTime Battery 1 | 0 h |
Software |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows 7 Professional, Windows Embedded 8.1 Industry |
| Operating System Installed | Windows 10 |
Dimensions and weight |
| Width | 280 mm |
| Height | 195 mm |
| Depth | 23 mm |
Operating Conditions |
| Operating Temperature | -20...60 °C |
Standards and Certifications |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock, MIL-STD-810G Test Method 516.4 Drop 120 cm |
