CPU | |
| Processor Installed | Intel Celeron J6412 |
| Max CPU frequency | 2.6 GHz |
Chipset | |
| Chipset | SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Intel UHD Graphics |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek HD Audio Codec |
Extension Slots | |
| M.2 | 2 |
Connectors | |
| Connectors | DB9, 2xHDMI, 2xRJ45, 4xUSB |
System Power Input | |
| Input Voltage DC | 12...19 V |
Power Supply | |
| Output Power | 65 W |
Dimensions and weight | |
| Width | 118 mm |
| Height | 44.4 mm |
| Depth | 109.4 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Standards and Certifications | |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-64 |
