Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Built-in, Desktop |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Gemini Lake |
| Processor Installed | Intel Pentium J5005 |
| Max CPU frequency | 2.8 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics 605 |
Ethernet | |
| Controller Type | Realtek RTL8111HS |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 5 |
| RS-232 | 5 |
| USB Total | 8 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC891 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| M.2 | 1 |
Connectors | |
| Connectors | DB15 VGA, HDMI, RJ11, RJ45 Ethernet, Audio Out, DC Input, Audio Mic |
System Power Input | |
| Input Voltage DC | 19...19 V |
| Power Consumption | 65 W |
Power Supply | |
| Type of Power Supply | DC-DC |
| Output Power | 65 W |
Dimensions and weight | |
| Width | 118 mm |
| Height | 74.4 mm |
| Depth | 109.4 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | IEC 60068-2-64. 5 Grms. random. 5 ~ 500 Hz. 1 hr / Per Axis. With SSD Non-operation: IEC 60068-2-6. 2 G. Sine. 10 ~ 500 Hz. 1 Oct/min. 1 hr / Per Axis |
| Shock | IEC 60068-2-27. 50 G. half sine. 11 ms duration. With SSD |
