Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Panel, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 8.4 " |
| Brightness | 450 Cd/m2 |
| Contrast Ratio | 600~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| СPU Generation/Family | Elkhart Lake |
| Processor Installed | Celeron N6211 |
| Socket | FCBGA1493 |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
LED / Controls | |
| LED | 1xHDD LED, Power LED |
| Controls | On/Off, 1xReset |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45 Ethernet, 2xUSB |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 50 W |
Software | |
| Operating System Compatibility | Ubuntu, Windows IoT Enterprise 10, Windows 11 |
Dimensions and weight | |
| Width | 275 mm |
| Height | 216 mm |
| Depth | 62 mm |
Standards and Certifications | |
| Certifications | CE/FCC |
