Construction | |
| Construction Chassis | Magnesium Alloy |
| Protection Level of Front Side (Panel) | IP54 |
| Protection Level of Chassis | IP54 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 8.4 " |
| Maximum resolution | 800x600 Dots |
| Brightness | 800 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Core i5-4200U |
| Max CPU frequency | 2.6 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
| SD Slots | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 512 GB |
Extension Slots | |
| SIM Card slots | Yes |
Antenna characteristics | |
| Cellular interfaces | 3G, 4G |
| Bluetooth | v4.0 |
Additional Functions | |
| GPS | GPS |
LED / Controls | |
| LED | 1xHDD LED, Battеry Status, Power LED, RFID LED |
| Controls | On/Off, 1xReset, Control Buttons |
Connectors | |
| Connectors | DB9, RJ45, 2xUSB, Audio |
System Power Input | |
| Input Voltage DC | 19...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Supported Types of Power Supply | External power adapter AC/DC |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 5200 mA*h |
| RunTime Battery 1 | 0 h |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows Embedded Professional 7 (64 bit) |
| Operating System Installed | Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 266 mm |
| Height | 220 mm |
| Depth | 50.5 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 515.6 Acoustic Noise |
