Construction | |
| Construction Chassis | Stainless Steel |
| Mounting Configuration | Panel, Wall, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP67 |
| Protection Level of Chassis | IP67 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Socket | CPU onboard |
| Max CPU frequency | 2.16 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 2 |
| USB 2.0 | 2 |
Audio | |
| Audio Controller | Realtek ALC886 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | 4xM12 |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 33 W |
Dimensions and weight | |
| Width | 311 mm |
| Height | 257 mm |
| Depth | 46.4 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
