Construction | |
| Mounting Configuration | Panel, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x600 Dots |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i5-5200U |
| Max CPU frequency | 2.7 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 16 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 64 GB |
Connectors | |
| Connectors | HDMI, 2xUSB, DC Input |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 284 mm |
| Height | 252 mm |
| Depth | 69 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
