Display | |
| Display Type | LCD TFT |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 1200~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Core i5 |
| Max CPU frequency | 2.5 GHz |
Memory | |
| Form-factor | DDR4 |
| Default on Board Memory | 4 GB |
| Maximum Memory | 16 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| 1st Storage Capacity | 64 GB |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45 Ethernet, 2xUSB |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Power Consumption | 32 W |
Dimensions and weight | |
| Width | 250 mm |
| Height | 315 mm |
| Depth | 67 mm |
