Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Panel, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 12.1 " |
| Maximum resolution | 1024x768 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 700 Cd/m2 |
| Contrast Ratio | 500~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | NXP i.MX6 dual-core |
| Socket | CPU onboard |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR3 |
| Socket Type | Soldered |
| Default on Board Memory | 1 GB |
| Assembly | Fixed on Board |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces | |
| MicroSD | 1 |
LED / Controls | |
| Controls | Control Buttons |
Connectors | |
| Connectors | 2xDB9, RJ45 Ethernet, DC Input, MicroSD card slot, USB type A |
System Power Input | |
| Input Voltage DC | 12...12 V |
Software | |
| Operating System Installed | Android |
Dimensions and weight | |
| Width | 252.4 mm |
| Height | 198 mm |
| Depth | 36.4 mm |
Operating Conditions | |
| Operating Temperature | -10...55 °C |
| Vibration | 2.18 g rms for XYZ/ 5-500Hz |
| Shock | 30g for 18ms |
Standards and Certifications | |
| Certifications | CE, FCC |
