Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Panel, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 12.1 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 500 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Tiger Lake |
| Processor Installed | Intel Core i5-1135G7 |
| Max CPU frequency | 4.2 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 1 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB v3.x | 4 |
Drive interfaces | |
| M.2 | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage External | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| 1st Storage Capacity | 128 GB |
Extension Slots | |
| Total | 3 |
| PCI Express x16 | 1 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, 1xReset |
Connectors | |
| Connectors | 3xDB9, 2xRJ45 Ethernet, 4xUSB, Audio, Display Port, DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 9...29 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 120 W |
Software | |
| Operating System Compatibility | Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 322 mm |
| Height | 256 mm |
| Depth | 91 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Vibration | MILSTD810G Method 514.6 |
Standards and Certifications | |
| Certifications | CE, FCC |
| Explosion safety | UL/cUL Class I Division 2 |
