Construction | |
| Mounting Configuration | Panel, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Diagonal | 15 " |
| Maximum resolution | 1024x600 Dots |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | ARM Cortex A9 |
| Max CPU frequency | 1.83 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 1 GB |
| Maximum Memory | 2 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB 2.0 | 1 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| MicroSD | 1 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 8 GB |
Connectors | |
| Connectors | 2xUSB, DC Input, Micro HDMI |
System Power Input | |
| Input Voltage DC | 12...12 V |
Dimensions and weight | |
| Width | 363.4 mm |
| Height | 277.9 mm |
| Depth | 44.5 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
