Construction | |
| Mounting Configuration | Panel, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Diagonal | 15 " |
| Maximum resolution | 1024x600 Dots |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 2 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 1 |
| USB 2.0 | 1 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 64 GB |
Connectors | |
| Connectors | DB9, 1xUSB, DC Input |
System Power Input | |
| Input Voltage DC | 12...12 V |
Dimensions and weight | |
| Width | 277.8 mm |
| Height | 363.4 mm |
| Depth | 44.5 mm |
Operating Conditions | |
| Operating Temperature | -15...55 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
