Construction | |
| Construction Chassis | Stainless Steel |
| Mounting Configuration | Panel, Wall, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Socket | CPU onboard |
| Max CPU frequency | 2.16 GHz |
Chipset | |
| Chipset | Intel Bay Trail-I SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 4 |
| USB Total | 6 |
| USB 2.0 | 6 |
Audio | |
| Audio Controller | Realtek ALC886 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 64 GB |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
Connectors | |
| Connectors | 4xM12 |
System Power Input | |
| Input Voltage DC | 12...12 V |
| Power Consumption | 38 W |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 80 W |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 378 mm |
| Height | 301 mm |
| Depth | 56.4 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
