Construction | |
| Construction Chassis | Stainless Steel |
| Mounting Configuration | Wall VESA 100, Wall |
| Protection Level of Front Side (Panel) | IP69K |
| Protection Level of Chassis | IP69K |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Aspect Ratio | 4:3 |
| Brightness | 250 Cd/m2 |
| Contrast Ratio | 700~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Kaby Lake |
| Processor Installed | Intel Core i5-7200U |
| Socket | CPU onboard |
| Max CPU frequency | 3.1 GHz |
Chipset | |
| Chipset | Intel Kaby Lake SoC |
Memory | |
| Socket Type | 1xSODIMM |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC886 |
Drive interfaces | |
| SATA 3 | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Installed drive | |
| 1st Storage Capacity | 128 GB |
LED / Controls | |
| LED | 1xOn/Off LED |
Connectors | |
| Connectors | M25 (2xUSB), M25 (COM), M25 (LAN), M25 (DC) |
System Power Input | |
| Power Consumption | 38 W |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows 10 |
Dimensions and weight | |
| Width | 378 mm |
| Height | 301 mm |
| Depth | 56.4 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
