Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Material Front Side (Panel) | Stainless Steel Front Panel |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
| Brightness | 550 Cd/m2 |
| Contrast Ratio | 2000~1 |
| Input Interface | VGA |
Touch Screen | |
| Touch Screen Type | Resistive |
| Interface | USB |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, KeyPad |
Connectors | |
| Connectors | M12 USB, M12 DC-in, M12 VGA |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Type of Power Supply | Industrial, External power adapter AC/DC |
Operating Conditions | |
| Operating Temperature | -20...50 °C |
| Vibration | MIL-STD-810G Method 514.6 |
| Shock | MIL-STD-810G Method 516.6 |
Dimensions and weight | |
| Width | 396 mm |
| Height | 310 mm |
| Depth | 49 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| Explosion safety | ANSI C1D2 12.12.01 |
| Oil And Gas | ATEX Zone 2 Ex nC IIC, UL/cUL Class I Division 2 Groups A/B/C/D |
| Safety | UL 60950-1, EN 60950-1 |
