Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Panel, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP66 |
| Material Front Side (Panel) | Aluminum |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15 " |
| Maximum resolution | 1024x768 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 700~1 |
| Input Interface | VGA, DVI-D |
Touch Screen | |
| Touch Screen Type | Resistive |
LED / Controls | |
| LED | 1xOn/Off LED |
| Controls | On/Off, Control Buttons |
Connectors | |
| Connectors | 2xDB9, DVI-D, DB15 VGA, DC input (terminal block), S-Video |
System Power Input | |
| Input Voltage DC | 24...24 V |
| Power Consumption | 40 W |
Operating Conditions | |
| Operating Temperature | -15...55 °C |
| Vibration | 5Hz~500Hz / 1Grms/3 Axis |
| Shock | 15G. 11ms duration |
Dimensions and weight | |
| Width | 412 mm |
| Height | 345 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| Marine grade | DNV, IACS-E10, IEC 60945 4th |
