Construction | |
| Construction Chassis | Stainless Steel |
| Protection Level of Chassis | IP67 |
Display | |
| Diagonal | 19 " |
| Maximum resolution | 1280x1024 Dots |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 1000~1 |
CPU | |
| Processor Installed | Intel Celeron N2930 |
| Max CPU frequency | 2.16 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Intel HD Graphics 4400 |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-232/422/485 | 1 |
Audio | |
| Audio Controller | Realtek ALC886 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 64 GB |
Extension Slots | |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | RJ45 Ethernet, 2xUSB |
System Power Input | |
| Input Voltage AC | 12...12 V |
| Power Consumption | 45 W |
Power Supply | |
| Type of Power Supply | AC-AC |
Dimensions and weight | |
| Width | 457 mm |
| Height | 370 mm |
| Depth | 62 mm |
Operating Conditions | |
| Operating Temperature | 0...45 °C |
