Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
| Protection Level of Chassis | IP20 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 19 " |
| Maximum resolution | 1280x1024 Dots |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Atom E3845 |
| Max CPU frequency | 1.91 GHz |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Realtek ALC886 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | 2.5" |
| Drive Interface | SATA |
| 1st Storage Capacity | 64 GB |
LED / Controls | |
| LED | 1xHDD LED, Power LED |
| Controls | On/Off, 1xReset |
Connectors | |
| Connectors | DB9, DB15 VGA, HDMI, 2xRJ45 Ethernet, 4xUSB, Audio, DC input (terminal block), Audio In |
System Power Input | |
| Input Voltage DC | 12...24 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 80 W |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 445.72 mm |
| Height | 370.46 mm |
| Depth | 79.6 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
