Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall VESA 100, Panel |
| Protection Level of Front Side (Panel) | IP66 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 19 " |
| Maximum resolution | 1280x1024 Dots |
| Brightness | 400 Cd/m2 |
| Contrast Ratio | 1000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | Intel Core i5-5350U |
| Max CPU frequency | 2.9 GHz |
Memory | |
| Form-factor | DDR3 |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 3 |
| USB 2.0 | 1 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | mSATA |
| 1st Storage Capacity | 128 GB |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off, Control Buttons |
Connectors | |
| Connectors | 2xDB9, 2xRJ45 Ethernet, DC Input, 3xUSB |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Windows Embedded Standard 8, Windows 7 Professional, Windows IoT Enterprise 10, Windows Embedded 8.1 Industry |
Dimensions and weight | |
| Width | 429 mm |
| Height | 382 mm |
| Depth | 72.8 mm |
Operating Conditions | |
| Operating Temperature | -15...55 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| Marine grade | IACS-E10 |
| Safety | IEC 60945 (4th) |
