R19IV7T-OFA1

R19IV7T-OFA1

Winmate
Ціна за запитом
Fanless Panel PC 19" SXGA TFT LCD, 1280 x 1024, Resistive Touch, Intel 3rd Gen Core i7/i5/i3 Processors, Up to 16GB DDR3L 1333/1600, 1xSATA2, 1xSATA3, VGA, 4x USB, 3xCOM, 2x RJ45 1000 Mbps, 2 x Mini PCIe,1 x PCIe(x16), 2x PS/2, Audio, 12VDC-in

Specification

Display

Display TypeLCD TFT
Diagonal19 "
Maximum resolution1280x1024 Dots
Brightness400 Cd/m2
Contrast Ratio1000~1

Touch Screen

Touch Screen TypeResistive

CPU

CPU Support TypeCore i3, Core i5, Core i7

Memory

Form-factorDDR3
Maximum Memory16 GB

Ethernet

Total Ethernet2
10/100/1000 Mbit/s2

Interfaces

COM Total3
RS-2322
RS-232/422/4851
USB Total4
USB v3.x4

Drive interfaces

mSATA1

Connectors

ConnectorsDB15 VGA, 2xRJ45 Ethernet, 2xPS/2 Keyboard/Mouse

System Power Input

Input Voltage DC12...12 V

Software

Operating System CompatibilityWindows Embedded Compact 7, Windows Embedded Standard 8, Windows IoT Enterprise 10

Operating Conditions

Operating Temperature0...50 °C

Files

Documentation

📄 R19IV7T-OFA1-Datasheet
