Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom D2550 |
| Max CPU frequency | 1.86 GHz |
Chipset | |
| Chipset | Intel NM10 |
Memory | |
| Form-factor | DDR3 |
| ECC | No |
| Default on Board Memory | 2 GB |
| Maximum Memory | 4 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel GMA 3650 |
Ethernet | |
| Controller Type | Realtek RTL8111 10/100/1000 Mbps |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 6 |
Drive interfaces | |
| CFast Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB44, DVI-I, DVI-D, 6xUSB, Mic In, Line In, Line Out, DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 10...32 V |
| Power Consumption | 30 W |
Software | |
| Operating System Compatibility | Windows XP Embedded, Windows 7, Windows Embedded Standard 7 |
Dimensions and weight | |
| Width | 252 mm |
| Height | 33 mm |
| Depth | 199 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
| Vibration | 3 Grms/5~500 Hz |
| Shock | CFast/SSD: Operating 40G (11ms) |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
