Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Tiger Lake |
| Processor Installed | Intel Core i5-1145G7E |
| Max CPU frequency | 4.1 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | 2xHDMI |
Ethernet | |
| Controller Type | Intel i226-IT |
| Total Ethernet | 3 |
| 2,5 Gbit/s | 3 |
Interfaces | |
| COM Total | 9 |
| USB Total | 6 |
| USB 2.0 | 2 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Total | 1 |
| M.2 | 1 |
| M.2 Form Factor | 2230 E |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | 6xUSB, 2xCAN (terminal block), Mic In, Line Out, 2xHDMI, 3xRJ45, GPIO (terminal block), 6xCOM (terminal block), DB9 |
System Power Input | |
| Input Voltage DC | 9...60 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Ubuntu 20.04 |
Dimensions and weight | |
| Width | 250 mm |
| Height | 170 mm |
| Depth | 62 mm |
Operating Conditions | |
| Operating Temperature | -40...60 °C |
| Humidity | 10-95% |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
