Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Desktop, Wall |
| Type | Fanless |
CPU | |
| Processor Installed | ARM Cortex |
Memory | |
| Form-factor | DDR4 |
| Socket Type | Soldered |
| Default on Board Memory | 32 GB |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| USB Total | 7 |
| USB 2.0 | 1 |
| USB v3.x | 6 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| MicroSD | 1 |
Extension Slots | |
| Total | 3 |
| M.2 | 2 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | 1 |
Antenna characteristics | |
| Cellular interfaces | 3G (Optional) |
Additional Functions | |
| GPS | GPS |
Connectors | |
| Connectors | 2xDB9, HDMI, 2xRJ45 Ethernet, 6xUSB, Audio Out, DC Input, 1xMicro USB, Audio In, 2xMini FAKRA, 1xDB50 (UART,SPI,CANbus,I2C,PWM,GPIO) |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Ubuntu |
Dimensions and weight | |
| Width | 190 mm |
| Height | 80 mm |
| Depth | 210 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
| Vibration | 3 Grms @ 5 ~ 500 Hz. random. 1 hr/axis |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Safety | CCC, UL, BSMI |
