System Architecture | |
| Form Factor | ATX |
CPU | |
| CPU Support Type | Core i3, Core i5, Core i7 |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDIMM |
| Maximum Memory | 64 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-D, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 14 |
| USB 2.0 | 8 |
| USB v3.x | 6 |
Audio | |
| Audio Controller | Realtek ALC886 |
Drive interfaces | |
| CompactFlash Slots | 1 |
Installed drive | |
| 1st Storage Capacity | 128 GB |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 1 |
| PCI Express x4 | 2 |
| PCI | 4 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | TPM, 24-pin ATX, 4x10-pin RS-232, 8x4-pin USB 2.0, 4-pin ATX, GPIO, CFEX, 19-pin USB 3.0, 6xSATA 3 |
| Connectors | 2xDB9, DVI-D, DB15 VGA, HDMI, 2xRJ45, 4xUSB, Audio (in/out/Mic) |
Dimensions and weight | |
| Width | 304.8 mm |
| Length | 243.8 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
