Construction |
| Construction Chassis | Rubber |
| Protection Level of Chassis | IP65 |
| Type | Fanless |
Display |
| Display Type | LCD TFT |
| Diagonal | 10.1 " |
| Maximum resolution | 1920x1200 Dots |
| Brightness | 800 Cd/m2 |
| Contrast Ratio | 800~1 |
Touch Screen |
| Touch Screen Type | Capacitive |
CPU |
| Processor Installed | ARM Cortex-A53 |
| Max CPU frequency | 2 GHz |
Memory |
| Maximum Memory | 4 GB |
Ethernet |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces |
| MicroSD | 1 |
Installed drive |
| 1st Storage Capacity | 32 GB |
Extension Slots |
| SIM Card slots | Yes |
Additional Functions |
| Camera Frontside | 8 MP |
| Rear Camera | 13 MP |
| GPS | GPS |
| RFID Reader | Optional |
| Sensors | Light Sensor, Accelerometer, Gyro, E-compass |
Antenna characteristics |
| Cellular interfaces | 4G (Optional) |
| Bluetooth | Yes |
LED / Controls |
| LED | Battеry Status, Power LED |
Connectors |
| Connectors | RJ45, 2xUSB, Mic In, Line Out, SIM Card Slot, MicroSD card slot, Micro HDMI |
| Docking Station | Yes |
System Power Input |
| Input Voltage DC | 19...19 V |
Power Supply |
| Type of Power Supply | External power adapter AC/DC |
Battery |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 3500 mA*h |
| RunTime Battery 1 | 10 h |
Software |
| Operating System Compatibility | Android |
Dimensions and weight |
| Width | 268 mm |
| Height | 187 mm |
| Depth | 22.2 mm |
Operating Conditions |
| Operating Temperature | -10...50 °C |
| Vibration | MILSTD810H Method 514.6 Procedure I |
| Shock | MILSTD810H Method 516.6 Procedure I |
Standards and Certifications |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810H Test Method 516.8 Shock, MIL-STD-810H Test Method 514.8 Vibration, MIL-STD-810H Test Method 516.8 Drop 3 ft |
