Construction | |
| Construction Chassis | Magnesium Alloy |
| Protection Level of Front Side (Panel) | IP50 |
| Protection Level of Chassis | IP50 |
| Type | Fan |
Display | |
| Display Type | LCD TFT |
| Diagonal | 15.6 " |
| Maximum resolution | 1980x1080 Dots |
| Aspect Ratio | 16:9 |
| Brightness | 400 Cd/m2 |
CPU | |
| СPU Generation/Family | Alder Lake |
| Processor Installed | Intel Core i5-1235U |
| Socket | CPU onboard |
| CPU Support Type | Core i5, Core i7 |
| Max CPU frequency | 4.4 GHz |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR5 |
| Socket Type | 2xSODIMM 262-pin |
| ECC | No |
| Default on Board Memory | 8 GB |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel Iris Xe Graphics |
| Interfaces | VGA, HDMI |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | Intel Wi-Fi 6E AX211 (802.11a/b/g/n/ac/ax) |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| M.2 | 2 |
| SD Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
| Slim Optical Disk Drive bays | 1 |
Installed drive | |
| Drive Type | SSD |
| Storage Form-Factor | M.2 |
| Drive Interface | PCIe x4 |
| 1st Storage Capacity | 256 GB |
Extension Slots | |
| M.2 | 2 |
| SIM Card slots | Yes, 1, Nano SIM |
Additional Functions | |
| Camera Frontside | 2 MP |
| GPS | Optional |
| RFID Reader | Optional |
| Smart Card Reader | Optional |
| NFC | Optional |
| Fingerprint Scanner | Optional |
Antenna characteristics | |
| Cellular interfaces | 4G (Optional) |
| Bluetooth | v5.3 |
Keyboard / Pointing Devices | |
| Type Keyboard | Waterproof |
| Layout | English, German |
| Type Mouse | TouchPad |
LED / Controls | |
| Controls | On/Off |
Connectors | |
| Connectors | DB9, DB15 VGA, HDMI, RJ45 Ethernet, 3xUSB, DC Input, USB type C, Audio, SIM Card Slot, Smart card slot, SD card slot |
| Docking Station | Yes |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 90 W |
| Input Voltage AC | 100...240 V |
Battery | |
| Battery 1 Technology | Li-ion |
| Battery Capacity | 7600 mA*h |
| RunTime Battery 1 | 12 h |
| Battery 1 Hotswap | Optional |
Software | |
| Operating System Compatibility | Windows 11 |
| Operating System Installed | Windows 11 |
Dimensions and weight | |
| Width | 375 mm |
| Height | 273 mm |
| Depth | 29.5 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
| Humidity | 5-95% |
| Temperature (Storage) | -40~+70 |
Standards and Certifications | |
| MIL-STD-810 | MIL-STD-810G Test Method 507.5 Humidity, MIL-STD-810G Test Method 510.5 Sand and Dust, MIL-STD-810G Test Method 514.6 Vibration, MIL-STD-810G Test Method 516.6 Shock, MIL-STD-810G Test Method 516.4 Drop 120 cm |
