System Architecture | |
| Form Factor | 3.5" |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | AMD LX800 |
| Max CPU frequency | 0.5 GHz |
Chipset | |
| Chipset | AMD CS5536AD |
Memory | |
| Form-factor | DDR |
| Socket Type | 1xSODIMM |
| Maximum Memory | 1 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Geode LX800 |
| Interfaces | LCD 18 bit, VGA |
Ethernet | |
| Controller Type | Realtek RTL8139DL |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB 2.0 | 4 |
| LPT | SPP, EPP/ECP |
Drive interfaces | |
| CompactFlash Slots | 1 |
Extension Slots | |
| Total | 1 |
| Mini-PCI | 1 |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | DB9, DB15 VGA, 1xPS/2, 2xRJ45 Ethernet, 1xUSB |
Dimensions and weight | |
| Width | 146 mm |
| Length | 104 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE |
