SCM9B-1421

Name: SCM9B-1421
Brand: Dataforth
SKU: 06107700
Availability: InStock

Dataforth

Ціна за запитом

DAQ Module, RTD type 100 Ohm @ 0C alpha = .00392, Input -200...+600 C, RS-232C, protocol ASCII

Специфікація

Specification

Construction
Construction Chassis	Plastic Chassis
Mounting Configuration	Wall
Analog Input
Total channels of analog input	1
Thermal resistance	RTD 100 Ohm
Digital Output
Total channels of digital output	1
Type	Open collector
Output voltage	0~30 V
Max. load current	30 mA
Interfaces
RS-232	1
Supported Protocols
Industrial Protocols	Dataforth slave
Connectors
Connectors	Screw Terminal
System Power Input
Input Voltage DC	10...30 V
Dimensions and weight
Width	91.4 mm
Depth	27.9 mm
Height	62.2 mm
Operating Conditions
Operating Temperature	-25...75 °C
Standards and Certifications
Certifications	CE
