SCM9B-1521

Name: SCM9B-1521
Brand: Dataforth
SKU: 06108700
Availability: InStock

Dataforth

Ціна за запитом

DAQ Module, Excitation Voltage +10 V, Input -30...+30 mV, RS-232C, protocol ASCII

Специфікація

Specification

Construction
Construction Chassis	Plastic Chassis
Mounting Configuration	Wall
Interfaces
RS-232	1
Supported Protocols
Industrial Protocols	Dataforth slave
Analog Input
Total channels of analog input	1
Load Cell	+/-30 mV
Digital Output
Total channels of digital output	1
Type	Open collector
Output voltage	3.5~30 V
Max. load current	30 mA
Connectors
Connectors	Screw Terminal
System Power Input
Input Voltage DC	10...30 V
Dimensions and weight
Width	91.4 mm
Depth	27.9 mm
Height	62.2 mm
Operating Conditions
Operating Temperature	-25...75 °C
Standards and Certifications
Certifications	CE
