Specification
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Wall |
Interfaces | |
| RS-232 | 1 |
Supported Protocols | |
| Industrial Protocols | Dataforth slave |
Analog Input | |
| Total channels of analog input | 1 |
| Voltage range | +/-10 mV |
Digital Input | |
| Total channels of digital input | 1 |
| Level of Logic "0" | 0~1 V |
| Level of Logic "1" | 3.5~30 V |
| Counter | 60Hz |
Digital Output | |
| Total channels of digital output | 2 |
| Type | Open collector |
| Output voltage | 3.5~30 V |
| Max. load current | 30 mA |
Connectors | |
| Connectors | Screw Terminal |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 91.4 mm |
| Depth | 27.9 mm |
| Height | 62.2 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
Standards and Certifications | |
| Certifications | CE |
