Specification
Analog Input | |
| io_tenso_bridge_type | full |
| Total channels of analog input | 1 |
| Voltage range | +/-10 mV, +/- 20 mV, +/-_30_mv, +/-50 mV, +/-100 mV |
Analog Output | |
| Channels of analog input | 1 |
| Current range | 0...20 mA |
| Voltage range | 0...5 V, 0...10 V, +/-5 V, +/-10 V |
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Connectors | |
| Connectors | Screw Terminal |
System Power Input | |
| Input Voltage DC | 10...30 V |
Dimensions and weight | |
| Width | 25 mm |
| Depth | 70 mm |
| Height | 114 mm |
Operating Conditions | |
| Operating Temperature | -25...75 °C |
| Humidity | 5-95% |
