Ethernet | |
| 10/100/1000 Mbit/s | 48 |
| 10 Gbit SFP+ Ports | 6 |
| ethernet_poe_1000mbit | 1 |
| ethernet_poe_standard | 802_3at |
Interfaces | |
| RS-232 | 1 |
Switch Properties | |
| MAC Table Size | 16 |
| Jumbo Frame Size | 9 kB |
Supported Protocols | |
| Protocol Layer 3 | VRRP, Static Routing, RIP V1/V2, OSPF |
| Managment Protocols | SNMPv1/v2c/v3, Telnet, TFTP, DHCP, SNMP, FTP, NTP, ICMP |
| Reservation protocols | VRRP |
| Security Protocols | SSH, TACACS+ |
| IEEE Standard | IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1S for Multiple Spanning Tree Protocol, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.1X for Authentication, IEEE 802.3 for 10BaseT, IEEE 802.3ab for 1000BaseT(X), IEEE 802.3ad for Port Trunk with LACP, EE 802.3af for Power-over-Ethernet, IEEE 802.3af/at for Power-over-Ethernet, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802ae for 10 Gigabit Ethernet, IEEE 802.3u for 100BaseT(X) |
Connectors | |
| Connectors | DB9, RJ45 |
System Power Input | |
| Input Voltage AC | 100...240 V |
Dimensions and weight | |
| Width | 440 mm |
| Depth | 300 mm |
| Height | 44 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
