System Architecture | |
| Form Factor | Half Size PICMG 1.3 |
CPU | |
| СPU Generation/Family | Coffee Lake |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel H310 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-I |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 8 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| M.2 | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 2xUSB 2.0, 10-pin DIO, 10-pin Audio, USB 3.0, 2xSATA, Display port |
| Connectors | DVI-I, 2xUSB |
Dimensions and weight | |
| Width | 126 mm |
| Length | 185 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
