Managed DIN-Rail Layer 3 Switch, 4x10GBase-X SFP+ ports, 8x1000Base-X,10/100/1000Base-T(X) Combo ports, 24x1000Base-X SFP ports, 16x10/100/1000Base-T(X) RJ45 ports, 220VAC/DC(85-264VAC/77-300VDC), redundant power inputs, IP40, IEEE 1588 -40...+75C


Switch Properties

Switch LevelLayer 3
Supported functionsBroadcast Storm Protection, Flow Control, MAC ACL, Rate Limit
MAC Table Size16000
Packet Buffer Size12 kBit
Max. Number of VLANs4000
Priority Queues8

Supported Protocols

Protocol Layer 3VRRP, RIP V1/V2, OSPF, PIM-DM, PIM-SM, Static Routing
Managment ProtocolsSNMPv1/v2c/v3, LLDP, Telnet, VLAN, SNTP Client, DHCP, RMON, TFTP, FTP, Syslog
Reservation protocolsRSTP, VRRP, DT Ring, DT Ring+, DT VLAN, DRP/DHP, MSTP
Security ProtocolsHTTPS, SSH, SSL, IEEE 802.1X Network Access Control, RADIUS
IEEE Standardieee_802.3i, ieee_802.3u, ieee_802.3ab, ieee_802.3z, ieee_802.3x, ieee_802.1p, ieee_802.1q, ieee_802.1w, ieee_802.1s, ieee_802.3ad

System Power Input

Redundant power inputYes
Power Supply Reserve input Voltage DC110...220 V
Power Supply Reserve input Voltage AC100...240 V


Construction ChassisMetal Chassis
Mounting Configuration19" Rackmount
Protection Level of ChassisIP40

Dimensions and weight

Width483 mm
Depth325 mm
Height88 mm

Operating Conditions

Operating Temperature-40...75 °C
MTBF460670 h

Standards and Certifications

EMIfcc_cfr47_part_15, en55032-cispr22_class_a
EMSIEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-16
SafetyIEC 62368-1, EN 62368
FreefallIEC 60068-2-32
Vibration And ShockIEC 60068-2-27, IEC 60068-2-6
