Ethernet |
| 10/100/1000 Mbit/s | 8 |
| Type 10/100/1000 Mbit/s | 8xRJ-45 |
| SFP 100/1000 Mbit Ports | 4 |
Switch Properties |
| Managed | Yes |
| Switch Level | Layer 2 |
| Supported functions | Rate Limit, Broadcast Storm Protection, Flow Control, Port Mirror |
| MAC Table Size | 32000 |
| Jumbo Frame Size | 10 kB |
| Max. Number of VLANs | 4000 |
| Priority Queues | 8 |
| IGMP Groups | 1000 |
Supported Protocols |
| Managment Protocols | VLAN, PVLAN, IGMP, GMRP, SNMPv1/v2c/v3, RMON, LLDP, Syslog, FTP, TFTP, SFTP, DHCP Server/Client, DHCP Option 82 |
| Reservation protocols | STP, RSTP, MSTP, DT Ring, DT Ring+, DRP/DHP, VRRP |
| Security Protocols | IEEE 802.1X Network Access Control, RADIUS, TACACS+, HTTPS, SSH, SSL |
| IEEE Standard | ieee_802.3i, ieee_802.3u, ieee_802.3z, ieee_802.3ad, ieee_802.3x, ieee_802.1p, ieee_802.1q, ieee_802.1w, ieee_802.1s, ieee_802.1x |
LED / Controls |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
System Power Input |
| Redundant power input | Yes |
| Input Voltage DC | 18...72 V |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP40 |
Dimensions and weight |
| Width | 91 mm |
| Depth | 140 mm |
| Height | 139 mm |
Operating Conditions |
| Operating Temperature | -40...85 °C |
| Humidity | 5-95% |
| MTBF | 1118569 h |
Standards and Certifications |
| EMI | fcc_cfr47_part_15, en55032-cispr22_class_a |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6 |
| Freefall | IEC 60068-2-32 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
