Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Ethernet |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces |
| COM Total | 1 |
| RS-485 | 1 |
Wi-Fi |
| Wi-Fi Standard | 802.11b/g/n |
Supported Protocols |
| Industrial Protocols | Modbus TCP server, Modbus RTU slave, MQTT client |
Digital Input |
| Total channels of digital input | 6 |
| Type | Wet contact |
| Level of Logic "0" | 0~4 V |
| Level of Logic "1" | 10~50 V |
| Sink/Source | Sink, Source |
| Isolation of Digital Input | 3750 V |
Digital Output |
| Total channels of digital output | 1 |
| Contact rating of relay (Form A) | 5A@250V AC, 5A@30V DC |
Additional Functions |
| Watchdog timer type | Hardware, Software |
System Power Input |
| Input Voltage DC | 10...48 V |
| Power over Ethernet (PoE) | PoE |
Dimensions and weight |
| Width | 33 mm |
| Depth | 108 mm |
| Height | 127 mm |
Operating Conditions |
| Operating Temperature | -25...75 °C |
Standards and Certifications |
| EMS | IEC 61000-4-2, IEC 61000-4-4 |
