Construction | |
| Mounting Configuration | Wall, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Display Type | LCD |
| Diagonal | 10.4 " |
| Maximum resolution | 1024x768 Dots |
| Aspect Ratio | 4:3 |
| Brightness | 1600 Cd/m2 |
| Contrast Ratio | 1000~1 |
| Input Interface | DVI, DisplayPort, VGA |
Touch Screen | |
| Touch Screen Type | Capacitive |
| Interface | RS-232, USB |
Connectors | |
| Connectors | DVI, DB15 VGA, DC Input, Display Port |
System Power Input | |
| Input Voltage DC | 9...48 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
| Humidity | 5-85% |
| Vibration | 1.5 Grms. 5-500 Hz. 3 Axis |
| Shock | 20 Grms. Half-sine 11 ms |
| Temperature (Storage) | -20~+70 |
Dimensions and weight | |
| Width | 280.6 mm |
| Height | 227.9 mm |
| Depth | 65.5 mm |
Standards and Certifications | |
| Certifications | CE/FCC |
