Construction | |
| Mounting Configuration | Panel, Wall, Wall VESA 100 |
| Protection Level of Front Side (Panel) | IP65 |
Display | |
| Display Type | LCD |
| Diagonal | 24 " |
| Aspect Ratio | 16:9 |
| Brightness | 1500 Cd/m2 |
| Contrast Ratio | 5000~1 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| СPU Generation/Family | Coffee Lake |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q370 |
Memory | |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 6 |
| RS-232/422/485 | 6 |
| USB Total | 5 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Realtek ALC888 |
Extension Slots | |
| Total | 4 |
| Mini-PCIe/Mini Card | 4 |
Connectors | |
| Connectors | 6xDB9, DVI, DB15 VGA, 3xRJ45 Ethernet, 6xUSB, Mic In, Line Out, DC Input, Display Port, 2xUSB (4-pin), 10-pin connector, Jack 3.5 |
Dimensions and weight | |
| Width | 584 mm |
| Height | 353 mm |
Operating Conditions | |
| Vibration | 1.5 Grms. 5-500 Hz. 3 Axis |
| Shock | 20 Grms. Half-sine 11 ms |
Standards and Certifications | |
| Certifications | CE/FCC |
