System Architecture | |
| Form Factor | Q7 CPU Module |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom N2600 |
| Max CPU frequency | 1.6 GHz |
Chipset | |
| Chipset | Intel NM10 |
Memory | |
| Form-factor | DDR3 |
| Socket Type | Soldered |
| ECC | No |
| Default on Board Memory | 2 GB |
| Maximum Memory | 2 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel GMA 3600 |
| Interfaces | DisplayPort, DVI, LVDS, HDMI |
Ethernet | |
| Controller Type | Intel 82574L 10/100/1000 Mbps |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| USB Total | 8 |
| USB 2.0 | 8 |
Audio | |
| Audio Controller | Intel HD Audio |
Extension Slots | |
| PCI Express x1 | 3 |
Additional Functions | |
| Watchdog timer type | Software |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Linux OS |
Dimensions and weight | |
| Width | 70 mm |
| Length | 70 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
