System Architecture | |
| Form Factor | COM Express Basic |
CPU | |
| Processor Installed | Intel Core i5-6442EQ |
| Socket | CPU onboard |
| Max CPU frequency | 2.7 GHz |
| Number of CPU | 1 |
Chipset | |
| Chipset | Intel QM170 PCH |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xDIMM |
| ECC | No |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LCD, VGA, DDI |
Ethernet | |
| Controller Type | Intel i219-V 10/100/1000 Mbps |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| USB Total | 12 |
| USB 2.0 | 8 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Extension Slots | |
| Total | 9 |
| PCI Express x16 | 1 |
| PCI Express x1 | 8 |
Additional Functions | |
| Watchdog timer type | Software |
Dimensions and weight | |
| Width | 95 mm |
| Length | 125 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
