System Architecture | |
| Form Factor | COM Express Basic |
Construction | |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Coffee Lake |
| Processor Installed | Intel Core i7-8850H |
| Socket | CPU onboard |
| Max CPU frequency | 4.3 GHz |
| Number of CPU | 1 |
Chipset | |
| Chipset | Intel QM370 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 3xSODIMM |
| ECC | No |
| Maximum Memory | 96 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | VGA, 2xLVDS 24 bit, 3xDDI |
Ethernet | |
| Controller Type | Intel i219-IT |
Interfaces | |
| COM Total | 2 |
| USB 2.0 | 8 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Intel HD Audio |
Additional Functions | |
| Watchdog timer type | Hardware |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 125 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
Standards and Certifications | |
| Certifications | CE/FCC |
