System Architecture | |
| Form Factor | COM Express Basic |
CPU | |
| Processor Installed | Intel Xeon D-1548 |
| Max CPU frequency | 2.6 GHz |
| Number of CPU | 1 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | Yes |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| USB Total | 8 |
| USB 2.0 | 4 |
| USB v3.x | 4 |
Extension Slots | |
| Total | 9 |
| PCI Express x16 | 1 |
| PCI Express x1 | 8 |
Additional Functions | |
| Watchdog timer type | Software |
Dimensions and weight | |
| Width | 95 mm |
| Length | 125 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
