System Architecture | |
| Form Factor | COM Express Compact |
CPU | |
| Processor Installed | Intel Core i3-4010U |
| Max CPU frequency | 1.7 GHz |
Memory | |
| Socket Type | 2xSODIMM |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel HD Graphics 4400 |
| Interfaces | LVDS, VGA, DDI |
Ethernet | |
| Controller Type | Intel i218 10/100/1000 Mbps |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| USB 2.0 | 8 |
| USB v3.x | 2 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| Total | 4 |
Additional Functions | |
| Watchdog timer type | Software |
Software | |
| Operating System Compatibility | Windows 7, Windows 10 |
Dimensions and weight | |
| Width | 95 mm |
| Length | 95 mm |
Operating Conditions | |
| Operating Temperature | -20...80 °C |
Standards and Certifications | |
| Certifications | CE |
