System Architecture | |
| Form Factor | COM Express Mini |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron N3060 |
| Max CPU frequency | 2.48 GHz |
| Number of CPU | 1 |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 2 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, LVDS, HDMI |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
Interfaces | |
| COM Total | 2 |
| USB 2.0 | 8 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Intel HD Audio |
Extension Slots | |
| Total | 3 |
| PCI Express x1 | 3 |
Additional Functions | |
| Watchdog timer type | Hardware |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Linux OS, Windows Embedded Standart 8.1 |
Dimensions and weight | |
| Width | 85 mm |
| Length | 55 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
