SOM304SX31PIBE1

SOM304SX31PIBE1

ICOP
Ціна за запитом
SOM304 Module Vortex86SX-300MHz CPU with 128MB DDR2, 4xCOM, 4xUSB, LAN, 2xGPIO, 512MB NAND Flash

Specification

System Architecture

Form FactorSystem on Module (SoM)

Construction

TypeFanless

CPU

CPU Support TypeVortex86
Processor InstalledVortex86SX
Max CPU frequency0.3 GHz

Memory

Form-factorDDR2
Socket TypeSoldered
ECCNo
Default on Board Memory0.13 GB
AssemblyFixed on Board

Graphic

Graphic ControllerIntegrated in Chipset

Ethernet

Controller TypeIntegrated with Chipset
Total Ethernet1
10/100 Mbit/s1

Interfaces

COM Total4
RS-2324
USB Total4
USB 2.04
LPTLPT

Digital Input-Output

Channels of DIO32

Additional Functions

Watchdog timer typeHardware, Software

Dimensions and weight

Width70 mm
Length70 mm

Operating Conditions

Operating Temperature-20...70 °C

Files

Documentation

📄 SOM304-PI
